airFiber 60 Xtreme-Range

The AF60-XR (airFiber 60 Xtreme-Range) is a multi-gigabit 60 GHz PtP bridge purpose-built for the most extreme long-distance wireless backhaul requirements across East Africa — delivering 5.4 Gbps total throughput (2.7 Gbps duplex) at ranges exceeding 15 km with a 5 GHz backup radio ensuring link continuity during adverse weather. Measuring 779 × 664 × 383 mm (30.7 × 26.1 × 15.1") and weighing 8.6 kg (19 lb) without or 13 kg (28.7 lb) with mount, the AF60-XR features a UV-stabilised polycarbonate and steel enclosure with galvanised steel precision alignment mount compatible with poles of 40–80 mm outer diameter. Powered by a Quad-core ARM® Cortex®-A53 at 1.4 GHz with 1 GB DDR3L memory. Operates in PtP mode only in bridge mode. Requires UISP web version 1.4.3 and later, UISP iOS version 2.20 and later, and UISP Android version 2.21.5 and later.

The 60 GHz main radio operates across 57–71 GHz worldwide with channel bandwidths of 2160, 1080, and 540 MHz and 16QAM, BPSK, and QPSK modulation with 1.4° × 1.4° precision beamwidth and 0° electrical downtilt. The 5 GHz WiFi 6 backup radio with 26 dBi dual-linear polarised antenna, 5° × 5° beamwidth, and 14 dB cross-pol isolation maintains link availability through East Africa's tropical rain events and atmospheric disruptions. Dual wired ports — (1) GbE RJ45 and (1) 1/10G SFP+ port — provide flexible connectivity options to high-capacity backhaul infrastructure. WPA2-PSK (AES) encryption with integrated GPS and Bluetooth management.

Advanced software features include:

• Wave AI and Wave Technology for automated optimisation
• UISP integration, ping watchdog, NTP client, and device discovery
• Antenna alignment, discovery utility, ping, speed test, and traceroute utilities
• Bridge mode networking

Additional specifications:

• Wind loading: 422 N at 200 km/h (94.86 lbf at 125 mph)
• Supported voltage range: 44–54V DC / 22–27V DC
• Management radio: 2400–2483.5 MHz
• Operating temperature: -40°C to 55°C (-40°F to 131°F)
• Operating humidity: 5–95% non-condensing
• FCC, IC, and CE certified, fully NDAA compliant

Ideal for ISP backbone infrastructure, extreme long-distance PtP links, remote site connectivity, and mission-critical wireless backhaul deployments across Kenya, Uganda, Tanzania, Rwanda, and the wider East and Central Africa region requiring 60 GHz 5.4 Gbps multi-gigabit throughput at 15+ km range, 5 GHz backup radio, dual GbE and 10G SFP+ ports, Wave Technology optimisation, and GPS synchronisation.
