U7 Lite (U7-Lite)

The U7 Lite (U7-Lite) is a compact, ceiling-mounted WiFi 7 access point designed for cost-effective wireless deployments. This dual-band WiFi 7 AP features 4 spatial streams (2x2 MU-MIMO on both 5 GHz and 2.4 GHz) delivering up to 4.3 Gbps on 5 GHz (BW240) and 688 Mbps on 2.4 GHz (BW40). The integrated antennas provide 5 dBi gain (5 GHz) and 4 dBi gain (2.4 GHz) for 115 m² (1,250 ft²) coverage.

The U7 Lite supports 200+ simultaneous connected devices with 802.11be (WiFi 7) and backward compatibility with WiFi 6/5/4 standards. PoE powered (42.5-57V DC, 13W max) enables efficient deployment with 2.5 GbE RJ45 uplink for high-speed backhaul. Compact dimensions of Ø171.5 x 33 mm (Ø6.8 x 1.3") and lightweight 313 g (11 oz) design simplify installation in space-constrained environments.

Operating temperature range of -30°C to 40°C (-22°F to 104°F) and 5-95% humidity tolerance support diverse installation environments. Max TX power of 24 dBm (5 GHz) and 23 dBm (2.4 GHz) provides reliable coverage. Advanced features include wireless meshing, band steering, 802.11v/r/k support, Passpoint (Hotspot 2.0), captive portal, PPSK, RADIUS over TLS (RadSec), and 8 BSSIDs per radio. Channel bandwidth support includes HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 MHz. Lite Mount included with UV-stabilized polycarbonate construction. UniFi Network version 9.0.114+ provides centralized management.

Ideal for small businesses, offices, retail stores, cafes, restaurants, residential deployments, and budget-conscious environments requiring WiFi 7 performance in a compact, cost-effective form factor.
