Ultra 60W

The USW-Ultra-60W (Ultra 60W) is a compact, Layer 2 managed Gigabit PoE switch delivering professional switching and PoE power delivery in an exceptionally versatile and space-efficient package. Measuring 203 × 76 × 33 mm (8 × 3 × 1.3") and weighing just 320 g (11.3 oz), the USW-Ultra-60W supports desktop, wall, and magnetic mounting — adapting to virtually any installation environment across East Africa, from server cabinet walls to under-desk magnetic attachment. The polycarbonate enclosure with included wall mount and AC adapter makes deployment straightforward. Requires UniFi Network version 8.0.7 and later.

The USW-Ultra-60W provides (7) GbE RJ45 PoE+ output ports (1G/100M/10M) at up to 30W per port and (1) GbE RJ45 port with optional PoE++ input — enabling the switch itself to be powered from a PoE++ source without requiring a separate power adapter. Total PoE availability varies by power input method — 52W with the included 60W AC adapter, 42W with PoE++ input, 202W with an optional 210W AC adapter — providing flexibility to scale PoE budget as deployment requirements grow. Switching capacity of 16 Gbps with 8 Gbps total non-blocking throughput and 12 Mpps forwarding rate ensures wire-speed performance across all ports simultaneously.

The comprehensive Layer 2 feature set includes STP and RSTP for loop prevention, egress rate limiting, flow control, storm control, multicast and broadcast rate limiting, port isolation, port mirroring, jumbo frames, and loop protection — providing enterprise-grade switching management in a compact desktop form factor. 256 supported VLANs and a 4,000 MAC address table support complex network segmentation requirements across small and medium East African business deployments.
Additional specifications: Max. power consumption: 9W excluding PoE output with PoE input / 8W with adapter input / 210W including PoE output with 210W AC adapter Heat dissipation: 31 BTU/hr excluding PoE output Supported voltage range: 50–57V DC/PoE Management via Ethernet Operating temperature: -30°C to 60°C with PoE++ input / -20°C to 45°C with 60W AC adapter input Operating humidity: 10–90% non-condensing Wall mount weight: 45 g (1.6 oz) / Adapter weight: 330 g (11.6 oz) CE, FCC, IC, and Anatel certified, fully NDAA compliant
Ideal for small offices, home labs, branch deployments, retail locations, hospitality environments, and distributed networks across Kenya, Uganda, Tanzania, Rwanda, and the wider East and Central Africa region requiring compact 8-port Gigabit PoE switching with 7 PoE+ output ports, 52W PoE availability, flexible desktop/wall/magnetic mounting, and full UniFi Layer 2 management in the most versatile and space-efficient PoE switch in the UniFi lineup.
