The Enterprise 8 PoE (USW-Enterprise-8-PoE) is a premium **Layer 3 managed network switch** engineered for organizations deploying enterprise-grade switching infrastructure with integrated routing and PoE capabilities. This **8-port 2.5 Gigabit switch** consolidates ultra-fast port connectivity, integrated PoE device power delivery, Layer 3 routing intelligence, and advanced security features into a single compact appliance. With 8 × 2.5 GbE PoE+ ports, 2 × 10G SFP+ uplinks, 80 Gbps switching capacity, 120W total PoE availability, and comprehensive Layer 3 routing, the Enterprise 8 PoE is the ideal solution for office networks, campus switching hubs, small-to-medium data centers, and enterprise deployments requiring professional-grade switching with integrated routing and high-capacity PoE delivery.
Whether you're deploying enterprise-grade network infrastructure with multi-gigabit switching, establishing Layer 3 routing between network segments and VLANs, powering extensive access point and device deployments, building high-performance campus network backbones, or expanding small-to-medium data center switching, the Enterprise 8 PoE delivers professional-grade performance, advanced routing intelligence, and comprehensive PoE power delivery for sophisticated network environments.
Key Features for Enterprise & Campus Deployments
- 8 × 2.5 GbE PoE+ Ports: All eight ports support 2.5 Gigabit speeds (with backward compatibility to 1G, 100M) with PoE+ delivery up to 32W per port—power devices while delivering high-speed connectivity
- Dual 10G SFP+ Uplinks: Two 10 Gigabit SFP+ ports for fiber or high-speed copper core connectivity—enable redundant or aggregated core connections
- 80 Gbps Switching Capacity: Professional non-blocking 40 Gbps throughput with 60 Mpps forwarding rate for demanding enterprise deployments
- 120W Total PoE Availability: Deliver up to 120W total PoE output across eight ports—sufficient for powering 3-4 high-power access points plus devices simultaneously
- Layer 3 Routing Capabilities: Integrated DHCP server, inter-VLAN routing, and static routing for local network segments—eliminates need for separate router in many deployments
- Advanced Security Features: 802.1X port-based authentication, MAC and IP-based ACLs, DHCP snooping, MAC address blocking, port isolation—enterprise-grade security controls
- 1,000 VLAN Support: Advanced network segmentation for security, guest networks, voice VLANs, and multi-tenant environments
- LACP Port Aggregation: Combine multiple ports for higher-capacity logical links—increases bandwidth and provides redundancy
- Advanced IGMP Configuration: Intelligent multicast management with querier, fast leave, and router port capabilities for video and streaming applications
- Managed via UniFi Network: Full integration with UniFi ecosystem—monitor, control, and troubleshoot from central management console
- Professional Management Interface: 1.3" touchscreen display for local monitoring and configuration
Perfect Applications Across Enterprise Environments
- Corporate Office Networks: Primary office switching hub with high-speed 2.5 GbE distribution and extensive access point power delivery
- Campus Backbone Switching: Distribution layer switch for university campuses, large properties, and multi-building facilities
- Small Data Centers: High-performance switching for small-to-medium server deployments and colocation facilities
- Branch Office Hubs: Advanced switching for larger branch locations requiring Layer 3 routing and professional switching infrastructure
- Hospitality Networks: Hotel and resort network infrastructure with high-capacity PoE for extensive access point deployments
- Retail Chain Distribution: Central location switching for multi-store retail operations with guest network segmentation
- Healthcare Enterprise: HIPAA-compliant hospital and clinic networks with VLAN segmentation and advanced security controls
- Education Institutions: Campus switching hub for universities, colleges, and schools requiring Layer 3 functionality and extensive device support
- Government Facilities: Secure government network infrastructure with advanced ACLs, VLAN segmentation, and compliance features
- Media & Broadcasting: High-bandwidth switching for broadcast facilities, content distribution, and professional media environments
Technical Specifications
- Port Configuration: 8 × 2.5 GbE RJ45 PoE+ ports (2.5G/1G/100M) + 2 × 10G SFP+ uplink ports (10G/1G).
- Switching Capacity: 80 Gbps total switching capacity with 40 Gbps non-blocking throughput and 60 Mpps forwarding rate.
- PoE+ Output: 8 × PoE+ ports delivering up to 32W per port (maximum 256W with full utilization); 120W standard PoE availability.
- Uplink Connectivity: Dual 10G SFP+ ports for fiber connectivity or high-speed copper uplinks—enable redundancy or link aggregation.
- Layer 3 Routing: DHCP server (local networks), inter-VLAN routing (local networks), and static routing capabilities for local network segmentation.
- Layer 3 Table Size: 512 ARP entries and 512 IPv4 routes for managing complex network topologies.
- Layer 2 Features: LACP port aggregation, Spanning Tree Protocol (STP/RSTP), advanced IGMP configuration, IGMP snooping, 802.1X port-based access control, MAC and IP-based ACLs (12 IPv4, 10 MAC), DHCP snooping and guarding, egress rate limiting, flow control, storm control, multicast/broadcast rate limiting, MAC address blocking, port isolation, port mirroring, jumbo frames, LLDP-MED, voice VLAN, loop protection, and virtual network override.
- VLAN Support: 1,000 VLAN support for advanced network segmentation, security policies, guest networks, and multi-tenant environments.
- MAC Address Table: 16,000 entry table for managing extensive network deployments with thousands of connected devices.
- Packet Buffer: 1.5 MB buffer for handling traffic bursts and optimizing performance during peak loads.
- Power Consumption: 30W base consumption (excluding PoE output); 150W maximum with full PoE output utilization.
- Power Input: Universal AC input (100-240VAC, 50/60 Hz) with internal 150W power supply.
- Management: Full UniFi Network integration (version 6.3.51+) for centralized monitoring, control, and troubleshooting; 1.3" touchscreen display for local management.
- Form Factor: Compact desktop (200 × 248 × 44 mm); lightweight at 2.4 kg; wall-mountable with integrated mounting hardware.
- ESD Protection: ±16kV air and ±12kV contact ESD protection for reliable operations in professional environments.
- Operating Temperature: -5°C to 45°C (23°F to 113°F)—suitable for climate-controlled office and data center environments.
- Certifications: NDAA compliant for government deployments; CE, FCC, IC certified for international operations.
Why Choose the Enterprise 8 PoE?
- ✅ High-Speed 2.5 GbE Ports: All eight ports support 2.5 Gigabit speeds—deliver future-proof multi-gigabit connectivity to modern workstations and devices
- ✅ Integrated Layer 3 Routing: Built-in DHCP, inter-VLAN routing, and static routing eliminate need for separate router in many deployments
- ✅ Dual 10G SFP+ Uplinks: Fiber connectivity with redundancy and aggregation options—enable flexible core network topologies
- ✅ 120W PoE Capacity: Deliver power to extensive access points and PoE devices without additional power infrastructure
- ✅ Enterprise-Grade Security: 802.1X, advanced ACLs, VLAN isolation, DHCP snooping—professional security without licensing fees
- ✅ Advanced IGMP Intelligence: Optimized multicast handling for video streaming, conferencing, and professional media applications
- ✅ 1,000 VLAN Support: Advanced segmentation for security, guests, voice, and complex multi-tenant architectures
- ✅ 16,000 MAC Addresses: Extensive device support for large campus and enterprise deployments with thousands of connected endpoints
- ✅ Port Aggregation: LACP support enables link bonding for higher capacity and redundancy
- ✅ Professional Management: UniFi Network integration plus 1.3" touchscreen for hybrid cloud/local management
High-Speed Layer 3 Architecture
80 Gbps Switching Fabric: Professional-grade switching capacity handles simultaneous high-speed traffic across all 2.5 GbE ports plus 10G uplinks without bottlenecks.
40 Gbps Non-Blocking Throughput: True non-blocking performance ensures full line-rate switching between any port combinations—no performance degradation under peak loads.
Integrated Layer 3 Routing: Local DHCP server, inter-VLAN routing, and static routing eliminate complexity and additional hardware in many network designs.
Dual 10G Uplink Options: Support for redundant or aggregated 10G connectivity enables sophisticated core network topologies with high reliability.
Professional Forwarding: 60 Mpps forwarding rate with 16,000 MAC entries and 512 IPv4 routes support complex, large-scale deployments.
Comprehensive PoE Power Delivery
120W Total PoE Capacity: Deliver up to 120W total PoE output across eight 2.5 GbE ports—sufficient for powering 3-4 high-performance access points plus devices.
32W Per-Port Delivery: Each port supports up to 32W PoE+ delivery—power demanding wireless access points and network equipment simultaneously.
Flexible Powering: Mix PoE+ devices of varying power requirements across eight ports with intelligent power management.
Extended Reach: 2.5 GbE PoE+ ports deliver high-speed performance alongside power delivery—eliminate network bottlenecks at access points.
Enterprise Security & Isolation Features
802.1X Port Authentication: Port-based network access control with integrated authentication—securely control network access at port level.
VLAN Segmentation: 1,000 VLAN support for advanced traffic isolation, guest networks, voice VLANs, and security zones.
Access Control Lists: 12 × IPv4 ACLs and 10 × MAC ACLs for granular traffic control and network isolation.
DHCP Protection: DHCP snooping and guarding prevent rogue DHCP server attacks—protect network infrastructure.
Advanced IGMP: Intelligent multicast management optimizes video streaming, conferencing, and professional media applications.
Perfect Complement to Enterprise Networks
- ✅ Campus Backbone: Serve as distribution layer switch for multi-building campus networks with Layer 3 routing
- ✅ Access Point Aggregation: High-capacity PoE and 2.5 GbE distribution for extensive wireless infrastructure deployments
- ✅ Server Connectivity: 2.5 GbE ports for modern servers and storage systems requiring high-speed networking
- ✅ 10G Core Integration: Connect via 10G SFP+ uplinks to enterprise core infrastructure for seamless scaling
- ✅ Multi-VLAN Networks: Layer 3 routing capabilities support sophisticated guest, voice, and segmented network architectures
Management & Integration
- UniFi Network Integration: Full managed switch support with version 6.3.51 and later—monitor and control from central console
- Local Touchscreen Management: 1.3" display for real-time monitoring and local configuration without network access
- Centralized Monitoring: Real-time port monitoring, traffic analytics, and health status visible from UniFi Controller
- Configuration Management: Apply VLAN settings, routing policies, and security configurations from central or local management
- Multi-Location Visibility: Manage Enterprise 8 PoE switches across all enterprise locations from single UniFi console
Related Products & Solutions
- Enterprise Switches (Modern) – Updated Enterprise switch models for PoE++ compatibility with latest U7/E7 access points
- UniFi Gateway Pro (UFG) – 10G enterprise security gateway for core network infrastructure
- UniFi Access Points – WiFi 6 infrastructure powered by Enterprise 8 PoE high-capacity delivery
- UniFi Switches (Multi-Gig) – Additional high-speed switches for expanding enterprise infrastructure
- CloudKey+ / CloudKey Enterprise – Centralized management for Enterprise 8 PoE and entire UniFi ecosystem
Order Now
Deploy the Enterprise 8 PoE at your network hub location today.
Order the **Enterprise 8 PoE (USW-Enterprise-8-PoE)** today and add professional Layer 3 switching with high-speed 2.5 GbE connectivity and comprehensive PoE delivery to your office, campus, or enterprise deployment. Perfect for sophisticated network architectures requiring integrated routing and extensive device power delivery.
For enterprise network architecture consultation, campus deployment planning, Layer 3 routing strategy, 2.5 GbE distribution design, high-capacity PoE planning, VLAN segmentation support, or comprehensive enterprise switching solutions—contact our team or **request a quote today**. We provide comprehensive technical support for enterprise network deployments, campus-wide infrastructure implementations, Layer 3 routing configurations, multi-site management, and end-to-end UniFi ecosystem solutions. Whether you're an enterprise IT director, campus network administrator, data center operator, or systems integrator, our team specializes in sophisticated, scalable enterprise switching infrastructure.
