SUMMARY:
The
USW-Ultra-210W (Ultra 210W) is a
compact Layer 2 managed PoE switch with 8-port Gigabit connectivity, 7 PoE+ output ports, and 202W high-capacity PoE availability for small offices and branch deployments across East Africa. This
compact desktop, wall, and magnetic-mount switch delivers:
(7) GbE RJ45 PoE+ output ports at up to 30W per port
(1) GbE RJ45 port with optional PoE++ input
202W total PoE availability with included 210W AC adapter
16 Gbps switching capacity and 8 Gbps non-blocking throughput
256 supported VLANs and 4,000 MAC address table size
Full Layer 2 feature set including STP/RSTP, storm control, port mirroring, loop protection, and jumbo frames
Flexible power input via included 210W AC adapter or PoE++
for small offices, branch locations, retail stores, and distributed network deployments across Kenya, Uganda, and the region.
Perfect for
small offices, branch deployments, retail locations, hospitality environments, and distributed networks requiring high-capacity PoE switching infrastructure with professional Layer 2 management capabilities, versatile desktop, wall, and magnetic mounting options in an
energy-efficient, space-saving form factor.
DATASHEET
DESCRIPTION:
The
USW-Ultra-210W (Ultra 210W) is a
compact, Layer 2 managed Gigabit PoE switch delivering high-capacity PoE power and professional switching in an exceptionally versatile and space-efficient package. Measuring
203 × 76 × 33 mm (8 × 3 × 1.3") and weighing just
320 g (11.3 oz), the USW-Ultra-210W supports
desktop, wall, and magnetic mounting — adapting to virtually any installation environment across East Africa, from server cabinet walls to under-desk magnetic attachment. The key differentiator over the Ultra 60W is the
included 210W AC adapter delivering 202W total PoE availability — nearly four times the PoE budget — enabling deployment of significantly more or higher-wattage PoE devices from a single compact switch. The
polycarbonate enclosure with included wall mount and 210W AC adapter makes deployment straightforward. Requires
UniFi Network version 8.0.7 and later.
The
USW-Ultra-210W provides
(7) GbE RJ45 PoE+ output ports (1G/100M/10M) at up to 30W per port and
(1) GbE RJ45 port with optional PoE++ input — enabling the switch itself to be powered from a PoE++ source without requiring the AC adapter.
Total PoE availability varies by power input method:
202W with included 210W AC adapter
52W with 60W AC adapter
42W with PoE++ input or 60W PoE adapter input
16W with PoE+ input
Switching capacity of 16 Gbps with 8 Gbps total non-blocking throughput and 12 Mpps forwarding rate ensures wire-speed performance across all ports simultaneously — powering and connecting access points, IP cameras, VoIP phones, and IoT devices simultaneously across East African office and retail deployments.
The comprehensive
Layer 2 feature set includes
STP and RSTP for loop prevention, egress rate limiting, flow control, storm control, multicast and broadcast rate limiting, port isolation, port mirroring, jumbo frames, and loop protection — providing enterprise-grade switching management in a compact form factor.
256 supported VLANs and a 4,000 MAC address table support complex network segmentation for multi-tenant and multi-department East African business deployments.
Additional specifications:
Max. power consumption: 9W excluding PoE output with PoE input / 8W with adapter input / 210W including PoE output with 210W AC adapter
Heat dissipation: 31 BTU/hr excluding PoE output
Supported voltage range: 50–57V DC/PoE
Management via Ethernet
Operating temperature: -30°C to 60°C with PoE++ input / -20°C to 60°C with 210W AC adapter input
Operating humidity: 10–90% non-condensing
Wall mount weight: 45 g (1.6 oz) / Adapter weight: 770 g (1.7 lb)
CE, FCC, IC, and Anatel certified, fully NDAA compliant
Ideal for
small offices, branch deployments, retail locations, hospitality environments, and distributed networks across Kenya, Uganda, Tanzania, Rwanda, and the wider East and Central Africa region requiring
compact 8-port Gigabit PoE switching with 7 PoE+ output ports, 202W high-capacity PoE availability, flexible desktop/wall/magnetic mounting, and full UniFi Layer 2 management in a space-efficient switch built for high-density PoE device deployments.
