The
UISP-P-Pro (UISP Power Pro) is a
high-capacity 1U rack-mount uninterruptible power management system purpose-built for large-scale WISP deployment sites — delivering up to 480W total 27V DC Power TransPort output across three independent outputs with dual PSU redundancy, SMS-over-LTE alert notifications, and external lead-acid battery backup for mission-critical East African ISP network infrastructure. Measuring
442.4 × 267.5 × 43.7 mm (17.4 × 10.5 × 1.7") and weighing
4.16 kg (9.2 lb), the UISP-P-Pro features an
SGCC steel and polycarbonate/ABS enclosure with a
1.3" touchscreen LCM display. Requires
UISP version 1.4.8 and later. Compatible with
UISP Console, UISP Router (with UISP Box), UISP Router Pro, UISP Switch (with UISP Box), and UISP Switch Pro.
The
UISP-P-Pro provides
(3) Power TransPort outputs at up to 250W each (27V DC) — delivering
240W total with 1 PSU or 480W total with 2 PSUs.
(2) PSU bays with 1 PSU included; an additional module is sold separately for full 480W redundant operation. The
(1) DC battery port accepts a 24V DC 20.83A lead-acid battery for extended backup runtime — connect lead-acid battery only, as other battery types could be hazardous. The
SMS-over-LTE (Cat M1) notification system with included external antenna supports
US/Canada FDD-LTE Bands 2, 4, 12, 13 (AT&T Network-Ready) and EU FDD-LTE Bands 1, 3, 8, 20, 28 — enabling remote SMS power alerts via a separately purchased nano-SIM from a Cat M1 SMS provider.
±15kV air and ±8kV contact ESD/EMP protection.
Management via Ethernet in-band and Bluetooth.
Additional specifications:
- Max. power consumption: 3W excluding Power TransPort output and battery charger
- Supported voltage range: 100–240V AC
- LTE antenna input: 5V DC, 0.5A
- Operating temperature: -10°C to 50°C (14°F to 122°F)
- Operating humidity: 5–95% non-condensing
- LED indicators: system status, RJ45 link/activity, Power TransPort on/off
- CE, FCC, IC, PTCRB, and AT&T certified, fully NDAA compliant
Ideal for
high-capacity WISP deployment sites, large-scale ISP power management, mission-critical outdoor network infrastructure, and enterprise ISP power redundancy deployments across Kenya, Uganda, Tanzania, Rwanda, and the wider East and Central Africa region requiring
480W total Power TransPort UPS output across three independent outputs, dual redundant PSU bays, SMS-over-LTE power alert notifications, external lead-acid battery backup, and UISP-managed power monitoring in a 1U rack-mount form factor.
