Standard 48 PoE (USW-48-POE)

The USW-48-POE (Standard 48 PoE) is a 1U rack-mount Layer 2 managed Gigabit PoE switch combining high-port-count PoE power delivery with completely silent fanless operation across 48 ports — purpose-built for East African enterprise environments where network density, PoE availability, and acoustic performance all matter. Measuring 442 × 285 × 44 mm (17.4 × 11.2 × 1.7") and weighing 4.5 kg (10 lb) without or 4.6 kg (10.2 lb) with mounting brackets, the USW-48-POE features an SGCC steel enclosure and mount, a 1.3" touchscreen LCM display, ±16kV/±12kV ESD protection, and supports rack depths of 400–1,200 mm (15.7–47.2"). Requires UniFi Network version 7.2.94 and later.

The USW-48-POE provides (32) GbE RJ45 PoE+ ports at up to 32W per port and (16) GbE RJ45 non-PoE ports with 195W total PoE availability — simultaneously powering dozens of access points, IP cameras, VoIP phones, and IoT devices across large East African enterprise and campus deployments. (4) 1G SFP uplink ports provide flexible fibre or copper uplink connectivity to core switching infrastructure. Switching capacity of 104 Gbps with 52 Gbps non-blocking throughput and 77 Mpps forwarding rate ensures wire-speed performance across all 48 ports simultaneously.

The comprehensive Layer 2 feature set includes:

• LACP port aggregation for link bonding and redundancy
• STP and RSTP for loop prevention
• Advanced IGMP configuration (Querier, Fast Leave, Router Port) and IGMP snooping
• 802.1X port-based access control
• MAC-based ACLs, IP-based ACLs, and device/network isolation
• DHCP snooping and guarding
• Egress rate limiting, flow control, storm control, multicast/broadcast rate limiting
• MAC address blocking, MAC-based port restriction, port isolation, port mirroring
• Jumbo frames, LLDP-MED, Voice VLAN, loop protection, virtual network override
• 128 IPv4 ACLs and 128 MAC ACLs

Additional specifications:

• Max. power consumption: 45W excluding PoE output / 240W including PoE output
• Heat dissipation: 153.5 BTU/hr excluding PoE output
• ESD protection: ±16kV air / ±12kV contact
• Operating temperature: -5°C to 40°C (23°F to 104°F)
• Operating humidity: 10–90% non-condensing
• CE, FCC, IC, and Anatel certified, fully NDAA compliant

Ideal for enterprise networks, data centres, server rooms, campus deployments, and large-scale organisations across Kenya, Uganda, Tanzania, Rwanda, and the wider East and Central Africa region requiring 48-port Gigabit PoE switching with 195W PoE availability, completely silent fanless operation, advanced Layer 2 management, and full UniFi Network integration in a high-density 1U rack-mount switch.
