The
USW-24 (Standard 24) is a
1U rack-mount Layer 2 managed Gigabit switch delivering 24 ports of wire-speed switching with completely fanless, silent operation — ideal for noise-sensitive East African environments including executive offices, hotel server rooms, reception areas, and quiet data closets. Measuring
442 × 200 × 44 mm (17.4 × 7.9 × 1.7") and weighing
2.7 kg (6 lb) without or 2.8 kg (6.2 lb) with mounting brackets, the USW-24 features an
SGCC steel enclosure and mount, a
1.3" touchscreen LCM display, and supports rack depths of
400–1,200 mm (15.7–47.2"). Requires
UniFi Network version 7.2.94 and later.
The
USW-24 provides
(24) GbE RJ45 ports (1G/100M/10M) and
(2) 1G SFP uplink ports with
52 Gbps switching capacity, 26 Gbps non-blocking throughput, and 39 Mpps forwarding rate — delivering wire-speed performance across all ports simultaneously. The
fanless cooling design ensures completely silent operation with
no moving parts, eliminating acoustic noise and reducing maintenance requirements.
The comprehensive
Layer 2 feature set includes:
- LACP port aggregation for link bonding and redundancy
- STP and RSTP for loop prevention
- Advanced IGMP configuration (Querier, Fast Leave, Router Port) and IGMP snooping
- 802.1X port-based access control
- MAC-based ACLs, IP-based ACLs, and device/network isolation
- DHCP snooping and guarding
- Egress rate limiting, flow control, storm control, multicast/broadcast rate limiting
- MAC address blocking, MAC-based port restriction, port isolation, port mirroring
- Jumbo frames, LLDP-MED, Voice VLAN, loop protection, virtual network override
- 128 IPv4 ACLs and 128 MAC ACLs
Additional specifications:
- Max. power consumption: 25W
- Heat dissipation: 85.3 BTU/hr
- Operating temperature: -5°C to 45°C (23°F to 113°F)
- Operating humidity: 10–90% non-condensing
- CE, FCC, IC, and Anatel certified, fully NDAA compliant
Ideal for
small-to-medium data centres, office networks, server rooms, noise-sensitive environments, and high-port-count switching deployments across Kenya, Uganda, Tanzania, Rwanda, and the wider East and Central Africa region requiring
24-port Gigabit switching with completely silent fanless operation, advanced Layer 2 management, and full UniFi Network integration.
