Gateway Max (UXG-Max)

Name: Gateway Max (UXG-Max)
Brand: Simplifi Networks

The Gateway Max (UXG-Max) is a compact, multi-WAN independent gateway engineered for high-performance networking at small-to-medium sites. This all-in-one security appliance combines up to 2.3 Gbps routing with integrated IDS/IPS, full 2.5 GbE port support, advanced threat protection, and flexible multi-WAN capabilities in an ultra-compact form factor. Perfect for small business networks, branch offices, remote locations, retail sites, and distributed deployments requiring enterprise-grade security and advanced routing without excessive complexity or cost.

Share Facebook X / Twitter

Kenya Uganda

About the Gateway Max (UXG-Max)

The Gateway Max (UXG-Max) is a premium compact multi-WAN independent gateway engineered for organizations seeking enterprise-grade security and high-performance routing in an extremely compact package. This standalone security gateway consolidates advanced threat protection, multi-WAN connectivity, and intelligent routing into a single powerful appliance that operates independently without requiring a separate UniFi OS Console. With up to 2.3 Gbps routing throughput with IDS/IPS protection, the UXG-Max is the ideal solution for small business networks, branch offices, remote locations, retail operations, and distributed deployments requiring professional networking infrastructure with unified security controls.

Whether you're protecting small-to-medium business networks, deploying multi-WAN redundancy at branch locations, establishing distributed network security, building remote office connectivity, or implementing zero-trust security models in compact spaces, the Gateway Max delivers the performance, reliability, and advanced threat detection required for professional operations.

Key Features for Small Business & Branch Deployments

Compact Multi-WAN Gateway: Measures just 141.8 × 127.6 × 30 mm (5.6 × 5 × 1.2 inches)—one of the smallest multi-WAN gateways available, perfect for space-constrained offices and retail locations
Full 2.5GbE Port Support: 1 × 2.5 GbE WAN port + 4 × 2.5 GbE LAN ports (one remappable to WAN) for flexible multi-WAN configurations and high-speed network connectivity
2.3 Gbps Routing with IDS/IPS: Enterprise-class throughput with integrated intrusion detection and prevention delivering 55,000+ threat signatures via CyberSecure for comprehensive threat protection
Independent Gateway Operation: Functions as standalone security gateway without requiring separate UniFi OS Console—managed via CloudKey Gen2+, Official UniFi Hosting, or UniFi Network Server
Advanced Multi-WAN Management: Multi-WAN load balancing, automatic failover detection, policy-based routing, and optional LTE backup for continuous connectivity across multiple internet connections
Enterprise Security Architecture: Stateful firewall, application-aware Layer 7 filtering, DPI traffic analysis, zone-based advanced filtering, content filtering, and ad blocking with 55,000+ IDS/IPS signatures
Enterprise VPN & SD-WAN: License-free SD-WAN, Site Magic VPN, IPsec, WireGuard, OpenVPN, L2TP, and Teleport zero-configuration VPN for secure remote access and branch connectivity
All Traffic Flows Analytics: Advanced netflow/sFlow visibility for comprehensive network monitoring, performance optimization, and troubleshooting
USB-C Powered: Ultra-low 9.6W power consumption with standard USB-C adapter (included)—ideal for office desks, retail counters, or mobile deployments
Cloud & Local Management: Flexible deployment options—CloudKey Gen2+, Official UniFi Hosting, or self-hosted UniFi Network Server for data sovereignty

Perfect Applications Across Organizations

Small Business Networks: Complete gateway solution for startups, SMBs, professional services, and growing companies requiring enterprise security in compact form
Branch Office Networks: Satellite gateway for branch locations, regional offices, and distributed team sites with multi-WAN redundancy and centralized security
Retail & Hospitality: Compact gateway for retail stores, restaurants, cafés, boutique hotels, and small hospitality venues needing guest networks and advanced security
Remote Office Locations: Ideal for remote work sites, temporary offices, and satellite locations requiring professional networking in minimal space
Professional Services: Legal offices, accounting firms, consulting practices, design studios, and service providers requiring secure, reliable connectivity
Healthcare Clinics: HIPAA-compliant gateway for smaller medical offices, urgent care clinics, and distributed healthcare locations with compliance requirements
Educational Facilities: Satellite gateway for school branches, training centers, libraries, and education institutions requiring distributed network management
Manufacturing & Industrial: Secure gateway for small manufacturing sites, warehouses, and industrial locations with IDS/IPS threat protection
Government & Public Sector: Branch office gateway for local government offices, public service locations, and municipal sites requiring secure, managed connectivity
Multi-Location Deployments: Deploy multiple UXG-Max units across organization branches with centralized security policy and unified management

Technical Specifications

Management Platform: Independent gateway operation managed via CloudKey Gen2+, Official UniFi Hosting, or UniFi Network Server (version 8.1.113+).
WAN Connectivity: 1 × 2.5 GbE RJ45 default WAN port with up to 4 additional 2.5 GbE ports remappable to WAN for multi-WAN configurations.
LAN Ports: 4 × 2.5 GbE RJ45 LAN ports (including one remappable port) for high-speed network connectivity and device connections.
Total Ports: 5 × 2.5 GbE ports providing maximum flexibility for multi-WAN setups and network expansion.
Routing Performance: 2.3 Gbps throughput with integrated threat inspection and advanced routing capabilities.
Security Features: Stateful firewall, application-aware Layer 7 filtering, DPI traffic identification, zone-based advanced filtering (regions, domains, apps), content filtering, ad blocking, IDS/IPS with 55,000+ signatures via CyberSecure.
VPN & Remote Access: Multi-protocol VPN support (IPsec, WireGuard, OpenVPN, L2TP), Site Magic VPN, Teleport zero-configuration VPN, and SD-WAN capabilities.
Network Routing: Advanced QoS, multi-WAN load balancing, dynamic routing (OSPF), policy-based routing, IPv6 support, integrated RADIUS server, RADIUS over TLS (RadSec), and advanced NAT.
Traffic Analytics: All Traffic Flows support with netflow/sFlow for comprehensive network visibility and performance monitoring.
Power & Efficiency: USB Type-C powered (5V DC/3A adapter included); ultra-low 9.6W max power consumption for minimal environmental impact.
Form Factor: Ultra-compact desktop design (141.8 × 127.6 × 30 mm); lightweight at 520g (1.1 lb); ideal for desk, shelf, or wall mounting.
Processor & Memory: Quad-core ARM Cortex-A53 at 1.5 GHz with 2GB system memory for handling multi-WAN operations and advanced threat detection.
MAC Address Table Size: 2,000 entries for managing network traffic across multiple sites and connections.
Operating Temperature: -10°C to 40°C (suitable for diverse indoor environments and climate conditions).
Certifications: NDAA compliant for government deployments; CE, FCC, IC certified.

Why Choose the Gateway Max?

✅ Ultra-Compact Design: Smallest multi-WAN gateway available—perfect for space-constrained offices, retail locations, and deployments where size matters.
✅ Independent Gateway Operation: Standalone appliance eliminates need for separate console, reducing costs and simplifying network architecture.
✅ Full 2.5GbE Support: All five ports support 2.5 GbE speeds, providing future-proof networking for emerging applications and high-bandwidth users.
✅ Multi-WAN Flexibility: Up to 4 WAN ports with remappable configuration enable custom multi-WAN topologies for redundancy and load balancing.
✅ Enterprise-Class Security: 2.3 Gbps routing with 55,000+ IDS/IPS signatures delivers professional threat protection without licensing fees.
✅ USB-C Powered: Ultra-low 9.6W consumption with included adapter—ideal for office desks, retail counters, or remote locations with limited power infrastructure.
✅ Advanced Traffic Analytics: All Traffic Flows visibility enables detailed network monitoring, performance optimization, and troubleshooting.
✅ Flexible Management: Choose between CloudKey, cloud hosting, or on-premise UniFi Network Server based on organizational requirements.
✅ Branch-Office Ready: Perfect for multi-location organizations deploying consistent security and networking policies across distributed sites.
✅ Cost-Effective Enterprise: Delivers enterprise-grade performance and security at accessible price point for small-to-medium businesses.

Multi-WAN Flexibility & Redundancy

Four Remappable WAN Ports: Configure up to 4 independent WAN connections from the five available 2.5 GbE ports for redundancy and load balancing across multiple internet providers. Automatic Failover: Intelligent failover detection ensures seamless transition between primary and backup WAN connections—no manual intervention required. Policy-Based Routing: Route specific traffic to preferred WAN connections based on application, destination, or user—optimize costs and performance simultaneously. LTE Backup Support: Optional integration with LTE backup systems provides continuous connectivity during primary internet outages. Load Balancing: Distribute traffic across multiple WAN connections to maximize bandwidth utilization and improve overall network performance.

Perfect Complement to Enterprise & SMB Networks

✅ Branch Office Gateway: Deploy UXG-Max at branch locations with central UDM-SE console for unified security and management
✅ Multi-Site Consistency: Maintain identical security policies and routing configurations across all branch offices from single management point
✅ Distributed Security: Each location independently protects against threats while reporting to central console for comprehensive visibility
✅ Scalable Growth: Add additional UXG-Max units as organization expands—no architectural changes required
✅ SMB to Enterprise Migration: Start with single UXG-Max, scale to larger deployments as business grows

Management & Deployment Options

CloudKey Gen2+ Console: Local management hub for on-premise security and control at central office
Official UniFi Hosting: Cloud-based management via Ubiquiti's secure hosted infrastructure
UniFi Network Server: Self-hosted management on customer infrastructure for maximum data sovereignty
Standalone Operation: Functions independently with LED indicators and Bluetooth connectivity for quick status checks

Related Products & Solutions

UniFi Gateway Pro (UFG) – Larger rack-mount 10G gateway for enterprise data centers and high-performance deployments
UDM-SE Dream Machine Special Edition – All-in-one console with 128GB NVR for centralized multi-site management
UDR7 Dream Router – Compact 10G gateway with integrated WiFi 7 for office primary deployments
CloudKey Gen2+ Console – Management hub for centralized control of multiple UXG-Max and UniFi devices
UniFi Switches – Multi-Gig switching to support 2.5GbE network infrastructure
UniFi Access Points – Wireless infrastructure extending from UXG-Max gateway

Order Now

Deploy the Gateway Max at your branch office or small business today.

Order the Gateway Max (UXG-Max) today and bring enterprise-grade security, multi-WAN redundancy, and professional network management to your small business, branch office, or distributed location. Perfect for growing organizations, multi-location retailers, service providers, and businesses requiring secure, reliable connectivity in compact form.

For network architecture consultation, multi-WAN deployment planning, branch office setup, integration with CloudKey or UniFi Network Server, or licensing assistance—contact our team or request a quote today. We provide comprehensive technical support for small business network deployments, branch office configurations, multi-location implementations, and migrations from legacy networking solutions to modern UniFi infrastructure.
