The Cloud Gateway Fiber (UCG-Fiber) is a high-performance 10G cloud gateway engineered for organizations requiring advanced gateway functionality, integrated switching, and video recording capabilities. This powerful desktop appliance delivers 5 Gbps IPS routing, dual 10G connectivity (SFP+ and RJ45), integrated 4-port 2.5 GbE switch with PoE+, and selectable NVR storage up to 2TB. Supporting 50+ UniFi devices, 500+ clients, and full UniFi application suite, the Cloud Gateway Fiber is ideal for medium businesses, branch networks, data centers, and organizations requiring high-speed gateway with integrated switching and video surveillance capabilities.
Key Features
- 10G High-Speed Connectivity: Dual 10G ports (1 × 10G SFP+, 1 × 10 GbE RJ45) for ultra-fast uplink and expansion
- 5 Gbps IPS Routing: Professional-grade 5 Gbps IDS/IPS throughput for high-performance network protection
- 50+ Device Management: Support for 50+ UniFi devices, 500+ clients, 50 access hubs, and up to 23 cameras
- Integrated 4-Port Switch: Built-in 2.5 GbE switch with PoE+ support (30W budget) for camera and device power
- Multi-WAN Support: Up to 6 WAN ports with intelligent load balancing and failover protection
- Selectable NVR Storage: NVMe SSD storage up to 2TB for video recording and retention
- Full UniFi Suite: Network, Protect, Access, Talk, and Connect applications for complete infrastructure management
- Advanced Security: Stateful firewall, Layer 7 firewall, IDS/IPS, DPI, content filtering, and ad blocking
- Quad-Core Processing: Quad-core ARM Cortex-A73 at 2.2 GHz for powerful gateway operations
- License-Free SD-WAN: SD-WAN capabilities without licensing fees for multi-location optimization
Perfect Applications
- Branch & Regional Networks: High-performance gateway for branch offices requiring 10G uplink and integrated switching
- Data Center Infrastructure: 10G gateway for data center operations with integrated video surveillance
- Medium Business Networks: Scalable gateway supporting 50+ devices with PoE switching for cameras and access control
- Hospitality & Retail Chains: Central gateway for multi-location networks with unified surveillance and management
- Campus & Enterprise Networks: High-speed gateway for campus deployments with integrated switching and NVR
- Healthcare Enterprise: Secure network gateway with surveillance and access control for healthcare facilities
Technical Specifications
- Device & Camera Support: Manages 50+ UniFi devices, 500+ clients, 15 HD / 8 2K / 5 4K cameras, 50 access hubs
- 10G Connectivity: 2 × 10G ports (1 × SFP+, 1 × RJ45) + 4 × 2.5 GbE RJ45 ports + 1 × 10G SFP+ LAN port
- Multi-WAN Capacity: Supports up to 6 WAN ports with load balancing and failover
- Routing Performance: 5 Gbps IDS/IPS throughput with professional-grade gateway capabilities
- Integrated Switch: 4-port 2.5 GbE switch with PoE+ (30W budget) for powered device connectivity
- NVR Storage: Selectable NVMe SSD up to 2TB for video recording and camera storage
- Processor: Quad-core ARM Cortex-A73 at 2.2 GHz for high-performance operations
- Memory: 3GB system RAM for smooth multi-tasking and concurrent operations
- Power: 54V DC/1.1A with included adapter; maximum 29.4W consumption (excluding PoE output)
- PoE Budget: 30W total PoE+ output for cameras, access hubs, and devices
- Firewall: Stateful firewall, Layer 7 application firewall, 55,000+ IDS/IPS signatures with CyberSecure
- Form Factor: Compact desktop (212.8 x 127.6 x 30 mm); polycarbonate enclosure
- Display: 0.96" LCM status display for real-time gateway and device monitoring
- Weight: 675g without SSD / 734g with SSD (1.5-1.6 lb)
- Temperature: Operating 0°C to 40°C; humidity 5% to 95% non-condensing
- Certifications: NDAA compliant; CE, FCC, IC, SRRC, Anatel certified; ESD/EMP protection
Why Choose Cloud Gateway Fiber?
- ✅ 10G High-Speed Connectivity: Dual 10G ports eliminate bandwidth bottlenecks for high-performance networks
- ✅ 5 Gbps IPS Routing: Professional-grade routing with advanced threat protection and detection
- ✅ Integrated 4-Port Switch: Built-in switching with PoE+ eliminates separate switch infrastructure
- ✅ Scalable Device Support: Manage 50+ devices and 500+ clients with unified gateway
- ✅ Flexible NVR Storage: Selectable SSD up to 2TB for customized video recording capacity
- ✅ Multi-WAN Capabilities: Up to 6 WAN ports with load balancing and redundancy
- ✅ Full UniFi Suite: Network, camera, access, VoIP, and wireless management included
- ✅ PoE+ Integration: 30W PoE budget powers cameras, access hubs, and wireless devices
- ✅ Powerful Processing: Quad-core A73 processor handles complex operations and high throughput
- ✅ Enterprise Ready: NDAA compliant for government and sensitive deployments
High-Performance Gateway & Switch
Dual 10G Ports: 10G SFP+ and 10 GbE RJ45 connectivity for ultra-high-speed network uplink and expansion.
Integrated 4-Port 2.5G Switch: Built-in switching with PoE+ support eliminates separate switch infrastructure.
5 Gbps IPS Routing: Professional-grade routing with advanced threat detection and prevention across all traffic.
Multi-WAN Load Balancing: Distribute traffic across 6 WAN ports for optimal performance and internet redundancy.
All-in-One Infrastructure: Gateway, switch, NVR, and security unified in single compact appliance.
Advanced Security & Networking
Layer 7 Firewall: Application-aware filtering with deep packet inspection and traffic identification.
55,000+ Threat Signatures: Comprehensive IDS/IPS protection with CyberSecure threat database.
VPN & SD-WAN: Site Magic, IPsec, OpenVPN, WireGuard, and license-free SD-WAN for secure connectivity.
Policy-Based Routing: Advanced NAT, dynamic routing, OSPF, and QoS for network optimization.
Camera & Access Integration: Full Protect and Access management with integrated PoE power delivery.
Perfect for Scalable Networks
- ✅ High-Performance Infrastructure: 10G connectivity supports demanding network requirements
- ✅ Integrated Switching: Built-in 4-port PoE switch reduces component count and complexity
- ✅ Comprehensive Management: Network, surveillance, access, and VoIP from unified platform
- ✅ Enterprise Scalability: Support for 50+ devices and 500+ users enables network growth
- ✅ Cost Efficiency: Single gateway replaces multiple components and infrastructure
Integration with UniFi Ecosystem
- UniFi Access Points – WiFi 5 and WiFi 6E infrastructure powered by integrated PoE
- UniFi Protect – Multi-camera surveillance with integrated NVR storage
- UniFi Access – Physical access control hubs powered by PoE integration
- UniFi Talk – VoIP telephone system integration and management
- UniFi Switches – Multi-gigabit switching expansion for network growth
- UniFi Cloud Console – Centralized management across multiple locations
Related Products & Solutions
- Cloud Gateway Max (UCG-Max) – 2.3 Gbps gateway with NVR for smaller deployments
- Cloud Gateway Ultra (UCG-Ultra) – 1 Gbps gateway without NVR storage
- CloudKey Enterprise (CK-Enterprise) – Enterprise management console for 1,000+ devices
- UniFi Gateway Pro (UFG) – Alternative 10G enterprise gateway option
- UniFi Protect – Dedicated NVR and camera management system
Order Now
Deploy the Cloud Gateway Fiber as your high-performance network gateway today.
Order the Cloud Gateway Fiber (UCG-Fiber) today and establish a powerful 10G gateway platform with integrated switching and video surveillance for your branch, campus, data center, or medium business network. Perfect for organizations requiring high-speed connectivity, integrated infrastructure, and unified device management.
For gateway deployment, 10G configuration, multi-WAN setup, NVR integration, or complete UniFi ecosystem implementation—contact our team or request a technical consultation today. We provide professional support for Cloud Gateway Fiber deployments and comprehensive enterprise network solutions.
