The
RG-NBS5100-24GT4SFP-P is a
premium 28-port Gigabit managed Layer 3 PoE+ switch with fiber uplinks, advanced routing capabilities, and industry-leading 5-year warranty engineered for advanced enterprise networks requiring Layer 3 routing, high-density PoE connectivity, and fiber uplinks. This
Gigabit Layer 3 PoE+ managed switch features
24 × 10/100/1000BASE-T Gigabit Ethernet PoE+ ports plus 4 × Gigabit SFP fiber uplink ports delivering
56 Gbps switching capacity and 41.66 Mpps forwarding rate for robust Layer 3 enterprise performance.
370W PoE budget with PoE/PoE+ support (IEEE 802.3af/at) on all 24 ports, maximum 30W per port, PoE power pins 1-2 (+), 3-6 (-) supports high-density deployments of IP cameras, VoIP phones, wireless access points, and IoT devices.
Intelligent PoE watchdog automatically monitors and reboots unresponsive PoE devices, ensuring maximum uptime for IP cameras and critical PoE equipment.
Advanced Layer 3 routing features with 500 IPv4 static routes and 128 IPv6 static routes enable comprehensive inter-VLAN routing, static routing, and network segmentation for complex multi-subnet enterprise environments.
Four Gigabit SFP fiber uplink ports enable high-speed fiber connectivity to core network or building-to-building links.
512 MB RAM and 256 MB Flash memory ensure robust operation and high-performance packet processing for demanding Layer 3 routing applications.
The
RG-NBS5100-24GT4SFP-P features
comprehensive Layer 3 switching capabilities including up to 4,094 VLANs, 16,000 MAC address entries, IEEE 802.1Q VLAN, Voice VLAN, STP/RSTP/MSTP (802.1d/w/s), LLDP, LLDP-MED, static MAC addressing, MAC address filtering, interface flow control, static aggregation, LACP, and inbound/outbound rate limiting with
advanced security features including 802.1X authentication (port-based and MAC address-based), RADIUS authentication, and Guest VLAN support.
Advanced QoS capabilities including 802.1p priority-based traffic classification, DSCP priority-based traffic classification, egress queues based on 802.1p and DSCP priorities, SP (Strict Priority), WRR (Weighted Round Robin), SP+WRR, and global QoS for optimized voice, video, and data applications.
Advanced interface features include jumbo frame support (9216 bytes MTU), Energy Efficient Ethernet (EEE), cable test diagnostics, and online firmware upgrades.
Flexible AC power input (100-240V AC, 50/60 Hz rated, 90-264V AC, 47-63 Hz maximum, 6A maximum input current) with fixed power supply, low 42.48W power consumption with no PoE load, maximum 431.8W consumption with full PoE load for efficient high-performance Layer 3 operation.
Operating across
wide environmental conditions: 0°C to +50°C operating temperature, -40°C to +70°C storage temperature, 10-90% RH operating humidity (non-condensing), wide altitude support (-500m to +5,000m) supports deployments in diverse climates across Kenya, Uganda, and East Africa.
Enterprise-class quality ensures high performance and reliability.
6kV surge protection reduces the possibility of port damage in harsh electrical environments, providing superior protection for valuable network equipment and connected devices.
ESD protection (Contact: 6 kV, Air: 8 kV), surge protection on service ports (±6 kV common mode) and power connector (±6 kV both common and differential mode), and MTBF of 400,000 hours ensure maximum reliability.
Multiple security policies protect your network with comprehensive access control and Layer 3 security capabilities.
Lifetime management on Ruijie Cloud platform enables remote monitoring, configuration, troubleshooting anytime anywhere.
Rack-mountable 1U design (440mm × 357.6mm × 43.6mm), dual fixed fans with left-to-right airflow, 49 dB acoustic noise at 25°C.
All service ports support hot swapping of cables.
Comprehensive certifications including CE, FCC, and international safety/EMC compliance (EN 55032, EN 61000-3-2/3-3, EN 55035, EN 300 386, IEC 62368-1).
Ideal for
enterprise campus distribution and access networks requiring Layer 3 routing, multi-VLAN enterprise environments with inter-VLAN routing, network segmentation and multi-subnet deployments, SMB networks with Layer 3 capabilities, high-density IP camera surveillance systems (up to 24 PoE cameras with PoE watchdog), VoIP phone deployments with routing and advanced QoS, wireless access point installations with fiber uplinks, branch office networks requiring Layer 3 routing requiring
premium managed Gigabit Layer 3 PoE+ switching with 24 PoE+ ports, 4 Gigabit SFP fiber uplinks, 370W PoE budget, advanced Layer 3 routing (500 IPv4/128 IPv6 routes), intelligent PoE watchdog, 56 Gbps switching capacity, 4,094 VLANs, comprehensive security (802.1X, RADIUS), advanced QoS (802.1p, DSCP, SP+WRR), jumbo frames (9216 bytes), 6kV surge protection, lifetime Ruijie Cloud management, rack-mountable 1U design, high reliability (400,000 hour MTBF), and industry-leading 5-year warranty across East Africa.
