airMAX PowerBeam 5AC
The PBE-5AC-Gen2 (airMAX PowerBeam 5AC Gen2) is a high-performance 5 GHz Point-to-Point bridge with integrated dish reflector, dedicated spectral analysis radio, and WiFi management radio for long-range wireless backhaul across East Africa. This 5 GHz PtP bridge with integrated dish and 25 dBi gain delivers:
Perfect for building-to-building links, campus connectivity, enterprise wireless backhaul, ISP infrastructure, remote site connections, and any deployment requiring high-performance 5 GHz PtP bridge with integrated dish antenna, dedicated management radio, and 15+ km link range across East and Central Africa.
DATASHEET
- 25 dBi integrated dish antenna gain
- 5 GHz operation — 5150–5875 MHz worldwide
- 15+ km link range
- 450+ Mbps throughput
- PtP channel sizes: 10/20/30/40/50/60/80 MHz
- PtMP channel sizes: 10/20/30/40 MHz
- Dedicated spectral analysis radio
- Dedicated WiFi management radio (2412–2472 MHz worldwide)
- Passive PoE 2-pair powered at 8.5W maximum (20–27V DC)
- 24V, 0.5A gigabit PoE adapter included
- (1) GbE RJ45 networking interface
- ±24 kV air/contact ESD/EMP protection
- 200 km/h wind survivability — 380 N wind loading (85.4 lbf at 125 mph)
- 420 × 420 × 230 mm (16.5 × 16.5 × 9.1") — 2.2 kg (4.9 lb)
- UV-stabilised plastic, powder-coated SPCC enclosure
- Pole mount kit included
Perfect for building-to-building links, campus connectivity, enterprise wireless backhaul, ISP infrastructure, remote site connections, and any deployment requiring high-performance 5 GHz PtP bridge with integrated dish antenna, dedicated management radio, and 15+ km link range across East and Central Africa.
DATASHEET
About the airMAX PowerBeam 5AC
The PBE-5AC-Gen2 (airMAX PowerBeam 5AC Gen2) is a high-performance 5 GHz Point-to-Point wireless bridge combining an integrated 25 dBi dish reflector, airMAX ac chipset, dedicated spectral analysis radio, and dedicated WiFi management radio in a single weatherproof outdoor unit for East African wireless backhaul and connectivity deployments. Measuring 420 × 420 × 230 mm (16.5 × 16.5 × 9.1") and weighing 2.2 kg (4.9 lb), the PBE-5AC-Gen2 features a UV-stabilised plastic and powder-coated SPCC enclosure with improved mounting and a pole mount kit included. Wind survivability of 200 km/h (125 mph) with 380 N wind loading. ±24 kV air/contact ESD/EMP protection. Environmental testing includes salt fog (IEC 68-2-11), vibration (IEC 68-2-6), temperature shock (IEC 68-2-14), UV (IEC 68-2-5), and wind-driven rain (ETS 300 019-1-4). Operating temperature: -40°C to 70°C (-40°F to 158°F). Fully NDAA compliant.
The PBE-5AC-Gen2 operates across 5150–5875 MHz worldwide delivering 450+ Mbps throughput over 15+ km links with 25 dBi integrated dish gain. PtP channel sizes of 10/20/30/40/50/60/80 MHz and PtMP channel sizes of 10/20/30/40 MHz provide flexible spectrum utilisation. The dedicated spectral analysis radio enables real-time RF environment monitoring without interrupting link traffic, and the dedicated WiFi management radio (2412–2472 MHz) allows remote management via UISP mobile app without impacting the main link. Powered via passive PoE 2-pair at 8.5W maximum (20–27V DC) with included 24V, 0.5A gigabit PoE adapter.
Additional specifications:
Ideal for building-to-building links, campus connectivity, enterprise wireless backhaul, ISP infrastructure, remote site connections, and PtP deployments across Kenya, Uganda, Tanzania, Rwanda, and the wider East and Central Africa region requiring 5 GHz 450+ Mbps PtP bridge performance with 25 dBi integrated dish, 15+ km range, dedicated spectral analysis, dedicated WiFi management, and airMAX ac technology.
The PBE-5AC-Gen2 operates across 5150–5875 MHz worldwide delivering 450+ Mbps throughput over 15+ km links with 25 dBi integrated dish gain. PtP channel sizes of 10/20/30/40/50/60/80 MHz and PtMP channel sizes of 10/20/30/40 MHz provide flexible spectrum utilisation. The dedicated spectral analysis radio enables real-time RF environment monitoring without interrupting link traffic, and the dedicated WiFi management radio (2412–2472 MHz) allows remote management via UISP mobile app without impacting the main link. Powered via passive PoE 2-pair at 8.5W maximum (20–27V DC) with included 24V, 0.5A gigabit PoE adapter.
Additional specifications:
- (1) Power LED, (1) LAN LED, (4) WLAN signal strength LEDs
- CE, FCC, IC, and RoHS certified, fully NDAA compliant
Ideal for building-to-building links, campus connectivity, enterprise wireless backhaul, ISP infrastructure, remote site connections, and PtP deployments across Kenya, Uganda, Tanzania, Rwanda, and the wider East and Central Africa region requiring 5 GHz 450+ Mbps PtP bridge performance with 25 dBi integrated dish, 15+ km range, dedicated spectral analysis, dedicated WiFi management, and airMAX ac technology.
