Ruijie Reyee RG-RAP2260 Wi-Fi 6 AX3000 Multi-G Ceiling Access Point

The RG-RAP2260 is a premium indoor ceiling/wall-mount Wi-Fi 6 access point with multi-gigabit uplink capability engineered for demanding high-density wireless deployments requiring future-proof wired backhaul. This 802.11ax AX3000 AP features 2×2:2 MU-MIMO on both 2.4 GHz and 5 GHz bands delivering up to 2,974 Mbps combined throughput: 573 Mbps on 2.4 GHz and 2,401 Mbps on 5 GHz. Revolutionary 2.5 Gigabit Ethernet uplink (10/100/1000/2500BASE-T) eliminates wired bottlenecks and future-proofs network infrastructure while the additional Gigabit Ethernet port (10/100/1000BASE-T) provides wired device extension or network redundancy. Dual-band operation with backward compatibility to Wi-Fi 5/4 (802.11ac/n/a/b/g) ensures support for legacy devices. Ultra-high client capacity supporting 500+ concurrent devices combined across both bands handles convention centers, exhibition halls, shopping malls, hotel lobbies, and other ultra-high-density environments with ease.


The RG-RAP2260 features dual Ethernet ports (1 × 2.5GbE + 1 × 1GbE) for maximum wired flexibility with PoE+ powered (IEEE 802.3at) or 12V DC/2A support and maximum 18W power consumption for simplified installation and low operational costs. Advanced 802.11k/v roaming support ensures seamless handoff between APs for uninterrupted connectivity across large venues. Compact ceiling/wall-mount design with 194mm × 194mm × 45.1mm dimensions and lightweight ≤0.65 kg blends elegantly into modern interiors including hotels, offices, malls, and premium venues. Advanced features include MU-MIMO, OFDMA for efficient multi-device performance, BSS coloring, TWT (Target Wake Time), Reyee Mesh technology for self-healing wireless mesh networks, built-in captive portal for guest WiFi authentication, VLAN support, QoS, band steering, and airtime fairness.

Operating temperature range of 0°C to 40°C (32°F to 104°F) supports tropical climate deployments across Kenya, Uganda, and East Africa. Management via Ruijie Cloud platform with real-time monitoring, firmware updates, and centralized configuration, Reyee mobile app, or standalone web GUI enables remote multi-site administration. Cloud-managed multi-gigabit WiFi perfect for businesses managing multiple high-density locations across East Africa. Flexible ceiling-mount or wall-mount installation with professional square form factor. NDAA compliant with CE, FCC certifications.

Ideal for large hotels and convention centers, shopping malls and food courts, enterprise campuses and tech parks, university facilities and student dormitories, large healthcare complexes and medical centers, sports venues and stadiums, airports and transportation hubs, government buildings and administrative centers requiring premium Wi-Fi 6 with AX3000 speeds, multi-gigabit 2.5GbE uplink, ultra-high client capacity (500+ devices), dual Ethernet ports, advanced 802.11k/v roaming, cloud management, and mesh networking across East Africa.
